Tank pressure management is a practical engineering discipline with direct consequences for safety, reliability, emissions, and operating cost.

In a recent webinar, Mastering Tank Pressure: Risks, Challenges, and Proven Solutions, Emerson’s Gerard Wittekoek outlined the pressure scenarios affecting fixed-roof storage tanks and the devices used to keep them operating within their design limits.

Why It Matters

Storage tanks may look static, but pressure inside them is constantly changing. Filling, emptying, solar heating, rain cooling, vapor generation, inert gas supply, and connected recovery systems can all affect the pressure in the vapor space above the liquid. If those pressure changes are not managed, a tank can exceed its maximum allowable working pressure or fall below its maximum allowable working vacuum. The result can be product loss, emissions, equipment damage, or more serious safety consequences.

Key Takeaways

• Tank pressure rises and falls during normal operations, including filling, emptying, heating, and cooling.
• Tank blanketing can help protect product quality, eliminate oxygen from the vapor space, lower the risk of fire and explosion, and reduce emissions.
• Vapor recovery systems capture vapors and route them to a safe location, for instance to a vapor recovery unit or flare.
• Breather valves protect against both overpressure and vacuum, working constantly to keep the tank within the design limits or as a backup system for tank blanketing and/or vapor recovery.
• Emergency relief valves provide large relief capacity for abnormal events such as nearby fire exposure, regulator failure, or when equipped with an extra vacuum relief, rapid tank emptying.
• Flame arrestors should be considered where flame ingress into the tank is a credible risk, even if a tank has operated for years without incident.

Pressure Starts with the Tank’s Vapor Space

A fixed-roof tank includes a liquid level and a vapor space. As liquid enters the tank, the vapor space decreases and the pressure rises. As liquid leaves the tank, the vapor space increases, and the pressure falls. If the pressure drops below atmospheric pressure, the tank experiences a vacuum.

Gerard explained that engineers must compare these changing pressures against the tank wall design limits: the maximum allowable working pressure and the maximum allowable working vacuum. Design standards such as API 620, API 650, and the European standard EN14015 guide allowable pressure conditions. Calculations for tank depressurization are described in API 2000.

Pressure changes also come from the environment. Sunlight can heat the tank, liquid, and vapor space, causing expansion and a rise in pressure. Rain or storms after a sunny period can quickly cool the tank, creating a vacuum. These thermal effects may require significant venting or increased breathing capacity, so they should not be treated as secondary concerns.

Tank Blanketing and Vapor Recovery Support Normal Operation

Tank blanketing and vapor recovery sit in the normal operating range of tank pressure management. Tank blanketing introduces an inert gas, often nitrogen or carbon dioxide, into the vapor space. Gerard noted that supply pressures of the inert gas may be several bar, while tank blanketing pressures are much lower, often around 10 millibar or less. Keeping blanketing pressure as low as practically possible can reduce inert gas consumption and operating cost.

The main purpose of tank blanketing is to eliminate oxygen in the vapor space. That can help preserve the stored product from oxidation, reduce oxidation of the tank itself, and reduce the likelihood of vapors igniting or exploding. It can also reduce vapor losses and emissions by maintaining positive pressure in the tank.

Vapor recovery works in the other direction. If pressure rises too much, a vapor recovery regulator opens and routes vapor away from the tank. The vapor may go to a safe location, either a vapor recovery unit or a flare. Vapor recovery helps reduce product loss and control emissions, especially where hazardous chemicals are involved.

Gerard also emphasized installation basics. For tank blanketing, locating the regulator near the vapor space helps avoid long pipe runs, pressure drops, remote-sensing complications, and condensate issues. Vapor recovery equipment can be larger and heavier, so ground-level installation may be more practical in some cases, particularly for service access.

Breather Valves, Emergency Relief, and Set Point Discipline

Breather valves manage both venting and inbreathing. If pressure rises, they relieve pressure. If vacuum develops, they open to supplement pressure. Gerard described conventional weight-loaded breather valves and explained that they can require significant overpressure to reach full lift and, with that, full capacity.

A conventional valve may need 100 percent overpressure to reach full capacity. That means a valve required to provide capacity at 20 millibar may need to be set at 10 millibar. Leakage can begin before the valve reaches set pressure, and the closer tank pressure gets to the set point, the more leakage can occur.

Gerard contrasted this with a high-capacity full-lift design that reaches full lift at 10 percent overpressure. In that case, the valve can be set closer to the required relief pressure while still delivering full capacity. Because the valve opens with a pop action, it will also have a blowdown; it will spend less time open and flowing compared with a conventional modulating valve. That can reduce product loss and emissions.

Emergency relief valves serve a different role. They open only under special conditions and are often large. For this reason, they are sometimes called manhole covers. A nearby fire can heat the liquid and create very large relief requirements, which is why these valves must provide huge capacity. They can also be equipped with a vacuum relief. Gerard pointed to vacuum-related incidents, such as rapid tank emptying due to a burst pipe or draining after hydrotesting, in which vacuum can exceed the tank’s allowable limit and cause collapse.

The practical message is simple: valves interact. If blanketing cannot supply enough gas, the pressure vacuum valve may open. If vapor recovery cannot handle the pressure rise, the pressure vacuum valve or emergency relief vent may open. Engineers should avoid operating too close to set points because leakage can begin before full opening, and leakage from emergency relief valves can be especially problematic. These devices may look rugged, but they are precision instruments and should be handled gently.

Flame Ingress and Emissions Deserve Attention

Gerard called flame ingress into storage tanks an underestimated risk. A breather valve is needed to keep pressure within the tank’s design limits, but it also provides an opening into the vapor space. If flammable vapor gathers near a vent and ignites, flame can travel toward the tank if adequate protection is not in place.

Tank blanketing can reduce this risk by filling the vapor space with inert gas. However, blanketing systems and inert gas supply can fail. A flame arrestor installed below a breather valve can help prevent flame from entering the tank. To size the flame arrestor correctly, engineers need to know the liquid in the tank and the flammable gases that may be present in the vapor space if blanketing is not working. It is not enough to say the service is nitrogen.

Gerard also described an integrated breather valve and flame arrestor design, the Anderson Greenwood 5910C combo. It includes flame arrestor elements on both the pressure and vacuum sides. Integration can reduce height and improve maintainability compared with placing a breather valve on top of a separate flame arrestor, though capacity still must be checked for the specific application.

Emissions are another pressure management issue. Gerard referenced European Union emissions regulations, best available techniques guidance, leak detection and repair, and the possibility of penalties for non-compliance or for excessive permitted emissions. His direction was practical: do not forget the equipment on top of the tank. Regular checks and repairs matter, especially where chemicals or regulated products are stored.

For engineers responsible for tank pressure management, the core lesson is to understand the sources of pressure, select devices for the actual operating conditions, and maintain them based on what service conditions reveal over time. To hear Gerard’s full presentation and question-and-answer discussion, watch the on-demand webinar and visit the Tank Pressure and Flame Protection section on Emerson.com.
